A standalone, header-based modern C++ implementation of the Dynamic Window Approach (DWA) — a local path planning algorithm for mobile robots that avoids obstacles while navigating toward a goal.
DWA samples candidate velocities within a dynamically computed feasible window (constrained by the robot's kinematic limits and acceleration bounds), simulates short trajectories for each candidate, and selects the velocity that minimizes a weighted cost over three criteria:
| Cost | Description |
|---|---|
| Heading | Penalizes angular deviation from the goal at the end of the predicted trajectory |
| Clearance | Penalizes proximity to obstacles (returns ∞ on collision) |
| Velocity | Penalizes low linear speed, encouraging forward progress |
Supports both circular and rectangular robot footprints.
src/
dwa.hpp — class definition, data structures, configuration
dwa.cpp — algorithm implementation
No external dependencies. Drop the two files into your project and include dwa.hpp.
#include "dwa.hpp"
// Use default configuration
DynamicWindowApproach dwa;
// Or provide a custom configuration
DynamicWindowApproach::Configuration config = DynamicWindowApproach::DEFAULT_CONFIGURATION;
config.maxSpeed = 1.0f;
config.robot_type = RobotType::RECTANGLE;
DynamicWindowApproach dwa(config);
// Set up inputs
Pose current_pose = {0.0, 0.0, 0.0}; // x, y, yaw [m, m, rad]
Velocity current_vel = {0.0f, 0.0f}; // linear [m/s], angular [rad/s]
Point goal = {5.0f, 5.0f}; // x, y [m]
PointCloud obstacles;
obstacles.points.push_back({1.5f, 1.5f}); // obstacle positions or LiDAR points
// Run one planning step
Velocity cmd = dwa.planning(current_pose, current_vel, goal, obstacles);
// cmd.linearVelocity → commanded linear velocity [m/s]
// cmd.angularVelocity → commanded angular velocity [rad/s]Call planning() at each control loop iteration with the robot's current state.
All parameters are in DynamicWindowApproach::Configuration. Default values:
| Parameter | Default | Unit | Description |
|---|---|---|---|
minSpeed |
-0.5 |
m/s | Minimum linear velocity (allows reversing) |
maxSpeed |
0.6 |
m/s | Maximum linear velocity |
maxYawrate |
3.2 |
rad/s | Maximum angular velocity |
maxAccel |
10.0 |
m/s² | Maximum linear acceleration |
maxdYawrate |
40.0 |
rad/s² | Maximum angular acceleration |
velocityResolution |
0.1 |
m/s | Linear velocity sampling resolution |
yawrateResolution |
0.1 |
rad/s | Angular velocity sampling resolution |
dt |
0.05 |
s | Simulation time step |
safety_distance |
0.5 |
m | Minimum clearance to maintain from obstacles |
predictTime |
1.0 |
s | Prediction horizon length |
robot_type |
CIRCLE |
— | RobotType::CIRCLE or RobotType::RECTANGLE |
robot_radius |
0.8 |
m | Robot radius (circle mode) |
robot_length |
1.0 |
m | Robot length (rectangle mode) |
robot_width |
0.9 |
m | Robot width (rectangle mode) |
heading_weight |
0.15 |
— | Weight for heading cost |
velocity_weight |
1.0 |
— | Weight for velocity cost |
clearance_weight |
1.0 |
— | Weight for clearance cost |
Prediction horizon (predictTime) is the most critical parameter. The heading cost is evaluated only at the last pose of the predicted trajectory, so the horizon must be long enough for the robot to clear obstacles and be pointing toward the goal by the end of the simulation. A horizon that is too short can cause the robot to get stuck behind obstacles.
Cost weights control the trade-off between speed, safety, and goal alignment. Increase clearance_weight for more conservative behavior near obstacles; increase heading_weight to prioritize pointing toward the goal.
